Grindex Dewatering Pump: Mini

Electrical submersible 1~ drainage pump

The Mini pump excels in applications where reliability and easy handling are essential. It is built to handle contaminated water, pH 5-8, and water containing relatively abrasive solids up to the size of 5 mm.

Available in both 50hz and 60hz models.

Grindex-Mini
Technical DataMini
Discharge connection2″
Rated output0.9 kW
Max power consumption1.2 kW
Rated current at 230 V5.2 A
Shaft speed2800 RPM
Strainer holes5 x 11 mm
Weight14.5 kg
Height440 mm
Width∅ 185 mm
Other voltages on request
Upper Mechanical Seal:
Carbon - Aluminium oxide
Lower Mechanical Seal:
Silicon carbide
Outer Casing:
Aluminium
Strator Housing:
Aluminium
Motor Shaft:
Stainless steel
Impeller:
Polyurethane
Lower Diffuser:
Polyurethane
Low Suction Collar:
On request
Float Switch:
On request
Other Castings:
Aluminium
Pump Raft:
On request
Screws & Nuts:
Stainless steel
O-Rings:
Nitrile rubber
Max. Liquid Density:
1100 kg/m3
Max. Liquid Temperature:
40°C
pH of Liquid:
5-8
Max Submersible Depth:
20m
Upper Mechanical Seal:
Carbon - Aluminium oxide
Lower Mechanical Seal:
Silicon carbide
Outer Casing:
Aluminium
Strator Housing:
Aluminium
Motor Shaft:
Stainless steel
Impeller:
Polyurethane
Lower Diffuser:
Polyurethane
Screws & Nuts:
Stainless steel
O-Rings:
Nitrile rubber
Other Castings:
Aluminium
Float Switch:
On request
Low Suction Collar:
On request
Pump Raft:
On request
Max Submersible Depth:
20m
pH of Liquid:
5-8
Max. Liquid Temperature:
40°C
Max. Liquid Density:
1100 kg/m3
