Grindex Slurry Pump: Bravo 200

Electrical submersible slurry pump

All slurry applications don’t require heavy duty pumps, and to meet this demand Grindex offer two smaller models, Bravo 200 and Bravo 300. They are intended for applications with lower demands on capability and wear resistance, and they are not equipped with agitator.

For capacities below these, we recommend Grindex sludge pumps.

Available in Explosion Proof version.
Available in both 50hz and 60hz models.

Discharge connection4″
Rated output4.7 kW
Max power consumption5.7 kW
Shaft speed1445 RPM
Rated current at 400 V9.6 A
Rated current at 500 V7.7 A
Throughlet50 mm
Max. Liquid Density:
1.7 kg/m3
Max. Liquid Density:
1.7 kg/m3
