Grindex Slurry Pump: Bravo 400

Electrical submersible slurry pump

Submersible slurry pumps for pumping fluids with abrasive solids
The Bravo 400 is extremely wear-resistant thanks to the use of Hard-iron™ and the low shaft speed. Equipped with an agitator to enhance the ‘up-stirring’ capabilities it is a superior quality pump for all kinds of slurry applications.

Available in Explosion Proof version.
Available in both 50hz and 60hz models.

Discharge connection4″
Rated output13.5 kW
Max power consumption16 kW
Shaft speed1455 RPM
Rated current at 400 V28 A
Rated current at 500 V21 A
Throughlet30 mm
Max. Liquid Density:
1.7 kg/m3
Max. Liquid Density:
1.7 kg/m3
