Grindex Slurry Pump: Bravo 500

Electrical submersible slurry pump

The Bravo 500 is extremely wear-resistant thanks to the use of Hard-Iron™ and the low shaft speed. Equipped with an agitator to enhance the ‘up-stirring’ capabilities it is a superior quality pump for all kinds of slurry applications.

Available in Explosion Proof version.
Available in both 50hz and 60hz models.

Discharge connection4″
Rated output18.5 kW
Max power consumption21 kW
Shaft speed1460 RPM
Rated current at 400 V36 A
Rated current at 500 V29 A
Throughlet40 mm
