Grindex Slurry Pump: Bravo 600

Electrical submersible slurry pump

The Bravo 600 is extremely wear-resistant thanks to the use of Hard-Iron™ and the low shaft speed.

It can be equipped with an agitator as an option to enhance the ‘up-stirring’ capabilities, but even without the agitator it is a superior quality pump for all kinds of slurry applications.

Available in Explosion Proof version.
Available in both 50hz and 60hz models.

Discharge connection4″
Rated output22 kW
Max power consumption25 kW
Shaft speed1460 RPM
Rated current at 400 V41 A
Rated current at 500 V33 A
Throughlet40 mm
Max. Liquid Density:
1.7 kg/m3
Max. Liquid Density:
1.7 kg/m3
