Grindex Slurry Pump: Bravo 800

Electrical submersible slurry pump

Submersible slurry pumps for pumping fluids with abrasive solids

The Bravo 800 is extremely wear-resistant thanks to the use of Hard-Iron™ and the low shaft speed. Equipped with an agitator to enhance the ‘up-stirring’ capabilities it is a superior quality pump for all kinds of slurry applications.

Available in Explosion Proof version.
Available in both 50hz and 60hz models.

Discharge connection6″
Rated output45 kW
Max power consumption49 kW
Shaft speed1475 RPM
Rated current at 400 V82 A
Rated current at 500 V63 A
Throughlet36 mm
Max. Liquid Density:
1.7 kg/m3
Max. Liquid Density:
1.7 kg/m3
